Part No. and Description Qty
HARDWARE IDENTIFICATION CHART
This chart is provided to help identify the hardware used in the assembly process. Place the washers, the
end of the bolts, or screws on the circles to check for the correct diameter. Use the small scale to check the
length of the bolts and screws.
NOTICE: The length of all bolts and screws except those with flat heads is
measured from below the head to the end of the bolt or screw.
Flat head bolts and screws are measured from the top of the
head to the end of the bolt or screw.
mm.
in.
INCHES
MILLIMETERS
11/2021/2 31/2 41/2 51/2 61/2
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
6 8 10 12
3/16" 5/16" 1/2"3/8"1/4"
length
length
After unpacking the unit, open the hardware bag and make sure that you have all the following items.
Some hardware may be already attached to the part.
101 Bolt, Socket Head (M6 x 1 x 35mm) 4
102 Bolt, Socket Head (M8 x 1.25 x 16mm) 4
103 Bolt, Socket Head (M8 x 1.25 x 25mm) 2
104 Bolt, Socket Head (M8 x 1.25 x 40mm) 4
109 Bolt, Button Head (M8 x 1.25 x 90mm) 4
110 Bolt, Button Head (M10 x 1.25 x 85mm) 2
106 Bolt, Button Head (M8 x 1.25 x 16mm) 4
108 Bolt, Button Head (M8 x 1.25 x 30mm) 2
113 Nylock Nut (M6 x 1) 4
114 Nylock Nut (M8 x 1.25 x 8mm thick) 10
116 Nylock Nut (M10 x 1.25) 2
55 Large Washer 2
118 Washer (M10) 2
119 Lock Washer (M8) 12
94 Screw, Round Head (M4 x 20mm) 4
95 Screw, Round Head (M5 x 20mm) 2
96 Screw, Round Head (M5x 0.8 x 20mm) 2
98 Bolt, Round Head (M8 x 1.25 x 16mm) 4
To Next Page
