Stamina InMotion Rower - STEP 3; STEP 4; STEP 5

ASSEMBLY INSTRUCTIONS
8
STEP 3
Insert the STOPPER SHAFT(30) through the hole in the CENTER BEAM(2). Screw two STOPPERS(29)
onto both ends of the STOPPER SHAFT(30) and tighten at the same time.
STEP 4
Attach the REAR SUPPORT(1) to the CENTER BEAM(2) with BUTTON HEAD BOLTS(M8x1.25x15mm)
(21) and WASHERS(M8)(12). Press The OVAL CAP(31) into the back end of the CENTER BEAM(2).
STEP 5
Attach the SHOCK(10) to the bracket at the front of the CENTER BEAM(2) with BUTTON HEAD BOLT
(M8x1.25x42mm)(11), WASHERS(M8)(12), and NYLOCK NUT(M8x1.25)(13).
