Standard PF-P310 - Line Diagram

（13）
Gate Solenoid
Upper
Sensor Receiver Sensor Projector
Lower
Sheet Presence mSW
Sheet Feed Solenoid
Drive Motor
Relay
Motor Capacitor
Terminal Board
AC Input
Power Supply
Power Switch
Fuse Holder
4A
Control P.C.B. QPW 444
Feed Tray Position mSW
Indication P.C.B. QPW 449
Sheet Delivery Cover mSW
Gate Solenoid
1-480319-0 1-480318-0
COM
NO
NO
COM
AR6622
NSKG115
ML-1765-4P
LCA30S-24
JW-L21RKK
F-65AB
CON2CON5CON3CON4
CON1
COM
NO
1-480319-0 1-480318-0
Y
G
D
1-480319-0 1-480318-0
CON1
CON2
COM
NC
Jumper Pin
8. Line Diagram
