Standard PF-P310 - User Manual

Questions and Answers

X
xcalderonJul 30, 2025
Why is my Standard Paper folding machine not folding correctly?
- P
  padillajayJul 30, 2025
  The folding result may be poor due to several reasons. The feed guides might be improperly set; adjust them to be right-angled with the front guide and parallel to each other. A fold roller spring could be loose, in which case you should replace it. The stopper in the buckle might be improperly set; with the power off and the power cord unplugged, ensure the leading edge of the sheet is parallel to the buckle stopper. Fold rollers might be dirty with ink, so clean them with an alcohol-soaked cloth. Sheets might be jammed in the buckle, so remove any jammed sheets. Support rollers might be improperly set, so readjust their position. The feed roller or double feed stop pad may be worn out, so replace them. Finally, a fold roller might be worn out, so replace it.
W
Wendy WheelerAug 3, 2025
What to do if my Standard Paper folding machine is misfeeding?
- A
  Alison AllenAug 3, 2025
  If your paper folding machine is misfeeding, it could be due to several reasons. The sheet might be too thick, exceeding the specified limits. The feed rollers might be worn out, requiring replacement. The feed tray may not be operating correctly due to a loose spring; inspect the feed tray movement or replace the spring in the feeding section. Alternatively, the sheet might be caught too tightly between the feed guides; adjust the feed guides to resolve this.
A
Amy ThompsonAug 8, 2025
How to fix wrinkles on folded sheets from Standard Paper folding machine?
- T
  taylorjamesAug 8, 2025
  Wrinkles on folded sheets can occur for several reasons. The sheets might be too thin or curled. The fold rollers might not be positioned properly; install them in the correct position. The fold rollers may be smeared with ink, so clean them with an alcohol-soaked cloth. The fold rollers might be deformed due to friction from long use, so replace them. Finally, the bush plates might have issues; check that they are not deformed and operate smoothly, then lubricate the fulcrum of the bush plate.
D
donaldwardAug 12, 2025
What to do if my Standard Paper folding machine is double feeding?
- J
  justinjonesAug 12, 2025
  If double feeding occurs, it may be because the sheet is too thin. Alternatively, the feed roller or double feed stop pad may be worn out; try cleaning the double feed stop pad or replacing it with a new one. Sheets may be sticking together due to ink, so fan the sheets well. Also, sheets may have static electricity, so fan the sheets well and try again a few minutes later.
C
Casey HernandezAug 16, 2025
Why Standard Paper folding machines (PF-P310) does not work?
- M
  Michael BrowningAug 16, 2025
  If the PF-P310 does not work with the start or test feed button, the start/stop button may be broken; consider replacing the switch or the entire P.C. Board. Alternatively, the feed clutch solenoid may not be positioned properly; adjust its position so that the clearance between the clutch lever and clutch stopper is 0.5 to 1 mm (0.02" to 0.04") while the feed clutch solenoid is on. Another possibility is that the sheet presence microswitch on top of the feed tray is broken, not positioned properly, or the connector is not connected properly; check the microswitch position or replace it after removing the feed tray.
T
tmoralesAug 20, 2025
How to adjust the deflector on a Standard Paper folding machine?
- D
  davidweaverAug 20, 2025
  If sheets are not being folded correctly with a single fold, it may be because the deflector is deformed or the deflector drive solenoid is not positioned properly. Adjust the deflector so that the clearance between the 2nd drive roller and the deflector is 0.9 to 1.3 mm (0.03" to 0.06") from the drive side to the operation side.
M
Mark MillsAug 26, 2025
Why doesn't the counter work on my Standard Paper folding machine?
- H
  hessrebeccaAug 26, 2025
  If the counter isn't counting sheets, the count sensor might be dirty; try cleaning the sensor. If the sheet size is irregular or the fold pattern isn't regular, select a short fold or accordion fold using the select button to provide an interval between each sheet. Also, check if a sheet is jammed in the sensor section or buckle and remove any jammed sheets.

Summary

Safety Instruction

General Safety Guidelines

Covers essential safety precautions, warnings, and cautions for operating and servicing the equipment.

Necessary Tool for Maintenance and Repair

Required Tools List

Lists essential tools like screwdrivers, wrenches, and snap-ring expanders for maintenance.

Signs and Abbreviations in This Manual

Wire Color Signs

Sign and color mapping for electrical wiring representation in diagrams.

Electronic Part Abbreviations

Abbreviations for electronic and electrical parts used within the manual.

Specifications

Operation Overview

Sheet Flow

How to Remove Cover

Troubleshooting

PF-P310 Not Working with Start;Test Button

Addresses issues with the start or test feed buttons not functioning.

Incorrect Single Fold

Solves problems where sheets are not folded correctly during single fold.

Folded Sheets Have Wrinkles

Provides solutions for wrinkles appearing on folded sheets.

Misfeed Occurs (Feed Roller Rotates)

Troubleshooting steps when misfeeds happen but the feed roller is rotating.

Double Feed Occurs

Addresses issues leading to multiple sheets being fed at once.

Folding Result Not Good

Solutions for various issues causing poor folding results.

Counter Does Not Count Sheets

Diagnoses and fixes when the sheet counter is not functioning.

How to Replace Count Sensor

Sensors and Electronic Parts Descriptions

Line Diagram

How to Replace Control Board

Standard PF-P310 Specifications

General

Model	PF-P310
Type	Paper Folding Machine
Folding Types	Letter, Double Parallel
Paper Size	A4, A5, B5, Custom Sizes
Paper Weight	40-120 gsm
Hopper Capacity	500 sheets
Power Supply	60Hz
