Standard PF-P310 - Specifications

（1）
1. Specifications
Model PF-P310
Type Desktop Type (Buckle built in)
Sheet Feed System Friction Roller
Sheet Size A3, A4
Sheet Width Maximum : 302 mm (11.9") Minimum : 65 mm (2.56")
Maximum Pile Height 21 mm (0.85")
Sheet Quality Normal Paper
Sheet Weight 50 to 105 gsm
Folding Speed 140 sheets / min. (A4, single fold)
Counter 4 digits
Fold Measure Indication Buckle stopper position lamp illuminates by pressing fold pattern
select button.
Fold Pattern Single Fold, Short Fold, Parallel Fold, Letter Fold, Accordion Fold,
Gate Fold, Cross Fold
Power 100 V 50/60 Hz
115 V 60 Hz
230 V 50 Hz
Power Consumption 65 W
Temperature & Humidity Temperature +5 ~ 45 ℃
Humidity 15 ~ 80 ％RH
Machine Dimension Tray Open : 771 x 485 x 316 mm (28" x 19.1" x 12.5")
Tray Close : 463 x 485 x 316 mm (18.3" x 19.1" x 12.5")
Machine Weight 29 kg (64 lb)
(During Operation)
