Machine Description
This section explains the machine description.
End Stopper
Sheet Guide
Feed Angle Adjusting Lever
Sheet Guide Locking Knob
Power Switch
Table
Refer to page 28
Refer to page 14
Sheet Detect Sensor
Gate Plate Height
Adjusting Lever
Table Height Adjusting Lever
For Stopper 1
For Stopper 2
For Control
For Pump
