Standard PF-P330 - Troubleshooting Common Issues; Fold Line Shifts and Skew Correction

28
Check first
There are two kinds of
Sheet guides are
set correctly along
the sheets.
Side View
Roller is clean. Sheet size setting
is correct.
A. Folding Skew
If the skew is in this direction,
Repeat the adjustment until the skew is removed.
Go to procedure B to remove the folding shift.
If the skew is in this direction,
A. Remove the folding skew
B. Folding Shift
Feed Angle Adjusting Lever
YES
NO
Start / Stop
Test Feed
Sheet Size
ing Pattern
8 1/2 " X 11"
8
1/2 " X 14"
5
1/2 " X 8 1/2 "
11"
X 17"
Fold Line Shifts
Adjust each part of the machine when the fold line shifts.
If both shifts and skew occur,
solve the skew first.
- Set the sheet guide correctly as the
figure shows.
- Clean the roller referring to [Roller
Cleaning/Replacement].
- Set the sheet size correctly.
Refer to page 42.
