Oil gets hot,
power unit
working hard.
Open center tool on a closed center
circuit and vice versa.
Use tools to match circuit.
Symptom Possible Cause Solution
Troubleshooting
Too much oil going through tool. Adjust flow for 12 gpm/ 45 lpm
maximum, or less.
Wrong hydraulic fluid. Circuit too
hot.
See OPERATING INSTRUCTIONS
for correct fluid/ circuit
specifications.
Oil leaks at
reversing spool.
Damaged o-rings. Replace as required.
12
Circuit relief set too low. Adjust relief valve to 2100 psi/ 145
bar.
Face o-ring worn or missing.
See your Authorized Dealer.
Oil leak at motor
cap face.
Fasteners loose. Tighten to specification (see service
manual.
Motor cap/ main housing damaged. See your Authorized Dealer.
