Specifications
Drive Size______ 1/2 in./ 1.3 cm 3-Jaw Adjustable
5/8 - 16 THD Chuck
Pressure Range______1000-
Flow Range_____________4-12 gpm / 15-45 lpm
Optimum Flow________________ 8 gpm / 30 lpm
Porting_______________________-8 SAE O-ring
Connect Size & Type___ 3/8
Weight_______________________ 6
Overall Length__________________ 9
Width_______________________ 3-1/2
Motor____________________________ Integral
System Type__open or closed center, HTMA TYPE I-III
2000 psi / 70-140 bar
in. NPT Male Adapter
lbs. / 2.7 kg
in. / 23 cm
in. / 9 cm
Drill Torque___20 ft lbs / 27 Nm at 2000 psi/ 140 bar
Drill Speed__________1000 rpm at 8 gpm/ 30 lpm
RPM Range______________________350-1500
Max. Fluid Temp._____________
HTMA Class II___________
EHTMA Category_____
Weighted Vibration Level____________1.2(m/s2)
Sound Pressure Level_Less than 85 dBA @ 1 m
140
30 lpm @ 138 bar
7-9 gpm @ 2000 psi
° F / 60° C
30Lpm at 138bar
BHTMA CATEGORY
Certificate of Conformity
I, the undersigned:
hereby certify that the construction plant or equipment specified hereunder:
1. Category:
2. Make:
3. Type:
4. Type Serial Number of equipment:
5. Year of manufacture:
Has been manufactured in conformity with- EEC Type examination as shown:
Directive:
6. Special Provisions:
Done at: Date:
Signature: Position:
Drill
Stanley
Stamped on tool
EN792-3
None
Stanley Hydraulic Tools, Milwaukie, Oregon USA 2002
Engineering Manager
DL0955001, & DL0965201
Date of expiration:
EN28662-1
EN ISO 3744
N/A
Approved body:
Date:
Self
2001
Surname and First Names
ALL
Winterling, David
DL09 TORQUE AND DRILL SPEEDS
TORQUE (proportional to Oil Pressure) Drill Speed (proportional to Oil Flow)
4 ft-lb @ 500 psi 5 Nm @ 35 bar
9 ft-lb @ 1000 psi 12 Nm @ 70 bar
14 ft-lb @ 1500 psi 19 Nm @ 105 bar
19 ft-lb @ 2000 psi 26 Nm @ 140 bar
USA METRIC
HYDRAULIC FLOW DRILL SPEED
3 gpm (11.3 lpm) 350 rpm
4 gpm (15 lpm) 475 rpm
6 gpm (23 lpm) 750 rpm
8 gpm (30 lpm) 1000 rpm
10 gpm (38 lpm) 1250 rpm
