Stanley Donard User Manual

8
EXPLODED VIEW
1. Front 2. Hob 3. Trivet 4. Riddling Handle 5. Side Panel RH 6. Back Panel 7. Side Panel Clamping
Bracket
8. Boiler Blanking Plate Upper 9. Short Thermostat Strip 10. Long Thermostat Strip 11. Donard SF Ashpan 12. Base 13. Lower Blanking Plate 14. Enamelled Front Cleaning
Door
15. Damper Assembly 16. Hotplate Cover 17. Boiler Assembly 18. Bonnet 19. Fire Door Assembly 20. Oven Door Assembly 21. Warming Door Assembly 22. Ash Door Assembly 23. RH Towel Rail Bracket 24. LH Towel Rail Bracket 25. Serial Number Plate 26. Steam Escape 27. Hotplate 28. Cleaning Plate To Hot Plate 29. Flue Top Back Guide 30. Flue Top Front Guide 31. One Piece Oven Base 32. Oven Bottom Back
33. Oven Bottom LH 34. Oven Bottom RH 35. Oven Bottom 36. Top Oven Top 37. Flue Way Right 38. Right Side Oven Top 39. Left Top Oven Side 40. Oven Top 41. Cleaning Plate To Hob 42. Cleaning Brush 43. Poker 44. Scraper 45. Roasting Tin 46. Oven Shelf 47. Stay Rod 48. Roasting Tin Grid 49. Ashpan Lifter 50. Towel Rail 51. Catch 52. Steam Vent 53. Stay Rod Nut 54. Stay Rod Nut Cup 55. Front Cleaning Door
Gasket
56. Front Door Cleaning Clip 57. RH Door Handle Assy 58. Thermometer 59. Warming Oven Door Panel 60. Main Oven Door Panel 61. Door Hinge 62. Thermostat
63. Protection Mesh 64. Extended Door Hinge 65. Ash Door Back 66. Spacer 67. Port Hole Cover 68. Thermostat Knob 69. Base Plate 70. LH Door Handle Assembly 71. Badge 72. Warning Label 73. Fire Door Back 74. Fix Plate LH 75. Fix Spindle 76. Fire Bar Link 77. Grate 78. Fire Bar 79. Baffle 80. Summer Side Brick
81. Riddling Grate 82. Summer Back Brick 83. Secondary Air Pipe 84. Summer Front Brick 85. Summer Grate Support 86. Oven Damper Knob 87. Damper Axle 88. 3” Butt Hinge 89. Hotplate Cover Panel 90. Spring Handle 91. Hotplate Cover Bracket LH 92. Hotplate Cover Bracket RH 93. Hotplate Cover Filler Plate 94. Hotplate Cover Stop 95. Bonnet Spin Valve 96. Bonnet Body 97. Bonnet Cleaning Door 98. Boiler Plug 99. Spin Valve 100.Hinge Sleeve 101.RH Fixing Plate
