by STANLEYFATMAX on this trimmer. Serious injury or
product damage mayresult.
Reload nylon line (either bulk or prewound replacement spool)
as shown in this manual.
USE ONLY 1.65 mm DIAMETER ROUND NYLON
MONOFILAMENT LINE. Do not use serrated or heavier gauge
line, as they will overload the motor and cause overheating. This
line is available at your local dealer or authorized servicecenter.
1. Remove battery from appliance.
2. Press the release tabs
19
on the spool cap
18
, and remove
the spool cap from the spool housing
10
(Figure K).
3. For best results, replace spool and line with
STANLEYFATMAX Model # STZST12169/STZST121693
or replace cap only with STANLEYFATMAX
Model#STZST1326.
4. If lever in base of housing becomes dislodged, replace in
correct position before inserting new spool intohousing.
5. Remove any dirt and grass from the spool cap and
spool housing.
6. Unfasten the end of the cutting line and guide the line into
the eyelet.
7. Take the new spool and push it onto the boss
20
in the
housing. Rotate the spool slightly until it is seated.
8. The line should protrude approximately 5-136mm from the
housing.
9. Align the release tabs on the spool cap with the slots in the
spool housing.
10. Snap the spool cap back on by depressing release tabs and
pressing into spoolhousing.
11. Push the cap onto the housing until it snaps securely
intoplace.
NOTE: Make sure that cover is fully positioned, listen for two
audible clicks to ensure both release tabs are correctly located.
Power the appliance on. In a few seconds or less you’ll hear the
nylon line being cut automatically to the proper length.
NOTE: Other replacement parts (guards, spool caps, etc.) are
available through authorized service centers.
Rewinding Spool from Bulk Line (use only
1.65 mm ROUND diameter line) (Fig. A, M, N)
Bulk line is also available for purchase from your local retailer.
NOTE: Hand wound spools from bulk line are likely to become
tangled more frequently than STANLEYFATMAX factory
wound spools. For best results, factory wound spools are
recommended.
1. Remove battery from appliance.
2. Remove the empty spool from the appliance as described in
Replacing Spool Assembly.
3. Remove any remaining cutting line from the spool
21
.
4. Make a fold at the end of the cutting line at about 19
mm. Feed the cutting line into one of the line anchoring
slots
22
.
5. Insert the 19 mm end of the bulk line into the hole
23
in
the spool adjacent to the slot. Make sure the line is pulled
tight against the spool.
6. Wind the cutting line onto the spool in the direction of the
arrow on the spool. Make sure to wind the line on neatly
and in layers. Do not crisscross.
7. When the wound cutting line reaches the recesses
24
cut
the line.
8. Fit the spool onto the appliance as described in Replacing
Spool Assembly.
MAINTENANCE
Your STANLEYFATMAX power tool has been designed
to operate over a long period of time with a minimum of
maintenance. Continuous satisfactory operation depends upon
proper tool care and regularcleaning.

WARNING: To reduce the risk of serious
personal injury, turn tool off and disconnect battery
pack before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
The charger and battery pack are notserviceable.
Lubrication
Your power tool requires no additionallubrication.
Cleaning

WARNING: Blow dirt and dust out of the
main housing with dry air as often as dirt is seen collecting
in and around the air vents. Wear approved eye protection
and approved dust mask when performing thisprocedure.

WARNING: Never use solvents or other harsh
chemicals for cleaning the non-metallic parts of the
tool. These chemicals may weaken the materials used in
these parts. Use a cloth dampened only with water and
mild soap. Never let any liquid get inside the tool; never
immerse any part of the tool into aliquid.
Optional Accessories

WARNING: Since accessories, other than
those offered by STANLEYFATMAX, have not been tested
with this product, use of such accessories with this tool
could be hazardous. To reduce the risk of injury, only
STANLEYFATMAX recommended accessories should be
used with thisproduct.
Consult your dealer for further information on the
appropriateaccessories.

Stanley FATMAX V20 Specifications

General

Battery Voltage	18V
Line Diameter	1.6 mm
Battery Type	Lithium-Ion
Line Feed	Automatic
Variable Speed	Yes
Power Source	Battery
Runtime	Up to 40 minutes
