*for complete tool explosion and Bill of Material please see service manual
ACCESSORIES CHANGING INSTRUCTIONS
Always wear approved hearing and eye protections at all times when using installation
equipment.
WARNING: Before adjusting tool, always remove the battery pack.
Mounting the mandrel and nosepiece
• Select the correct mandrel (A) and nosepiece (B) for the blind nut (K) to be
installed.
• Loosen the nose housing nut (E), Remove the nose housing (D).
• Press the mandrel lock (F), Loosen and remove the mandrel (A).
• Screw the correct mandrel (A) into Spin Pull Head (H) while pressing the mandrel
lock (F). Lock the mandrel (A)
• Loosen the lock nut (C) and unscrew and remove the nosepiece (B) and Lock nut
(C)
• Screw the Lock nut (C) onto the correct nosepiece (B) and screw the nosepiece (B)
into the nose housing (D) lightly.
• Adjust the position of the nosepiece (B) according to the blind nut (K) to be
installed. The length of mandrel protruding from the top of blind nut (K) to be 0-
0.5mm.
• Tighten the lock nut (C) by a spanner properly.
To Next Page
