Stanley ProSet XT2 Service Manual

12
ENGLISH
2.4 MAIN COMPONENTS LIST
Refer to gure 1 & 2 and the table below.
Item Part Number Description Qty
1
TRM00360 Standard nose equipment XT1 tool
1
TRM00361 Standard nose equipment XT2 tool
2 TP144-171 Suspension hook 1
3 TRM00227 Mandrel collector 1
4 07001-00405 Oil plug 1
5 07003-00194 Seal 1
6 76003-02008 Trigger 1
7 TRM00221 On/O valve 1
2.5 STANDARD NOSE EQUIPMENT
Refer to gure 2 and the table below.
Item
XT1 tool
Part Number
Description Qty
1a
PRN314 Nose Piece - 2.4mm [3/32”]
1
- Nose Piece - 4.8 mm [3/16”] (tted on XT2)
1b PRN414 Nose Piece - 3.2 mm [1/8”] (tted on XT1) 1
1c PRN514 Nose Piece - 4.0 mm [5/32”] 1
1d TP144-111 Nose housing 1
1e TP144-091 O-ring 1
1f DPN239-006 Jaw guide 1
1g PRG402-8A Jaws 1 Set
1h TP144-117 Jaw pusher 1
1i TP144-118 Urethane washer 1
1j TP144-119 Jaw pusher spring 1
1k TP144-120 Mandrel guide 1
1l TRM00167 Pulling head 1
1m TP144-113 Jaw guide lock 1
1n TP144-114 Jaw guide lock spring 1
1o DPN900-004 O-ring 1
1p TRM00238 Nose Housing Nut 1
For additional nose equipment please refer to the ProSet® Nose Equipment Manual 07900-09412 or visit
www.stanleyengineeredfastening.com/resource-center/document-library
For afull list of tool accessories, please refer to the ProSet Accessories Manual 07900-09413.
