1. Adequate clearance is required for the tool operator’shands before proceeding.
2. Do not abuse the tool by dropping or using it as ahammer.
• Care should be taken to ensure that spent mandrels do not create ahazard.
• The mandrel collector must be emptied when approximately half full.
• DO NOT use the tool without mandrel collector installed.
• DO NOT let air exhaust opening on the mandrel collector face in the direction of the operator or other
persons.
• Contact with hydraulic uid should be avoided. To minimise the possibility of rashes, care should be taken
to wash thoroughly if contact occurs.
• Material Safety Data Sheets data for all hydraulic oils and lubricants is available on request from your tool
supplier.
STANLEY Engineered Fastening policy is one of continuous product development and improvement
and we reserve the right to change the specication of any product without prior notice.
2. SPECIFICATIONS
The ProSet® XT1 are hydro-pneumatic tools designed to place Stanley Engineered Fastening blind rivets at
high speed.
The tools feature avacuum system for rivet retention and trouble free collection of the spent mandrels
regardless of tool orientation.
When coupled to the relevant nose equipment the ProSet® XT1 can be used to place blind rivets in the range
of Ø2.4mm to Ø4.8mm. Refer to the table on page 7 for alist of all rivets that can be placed.
The safety warnings on pages 4 & 5 must be followed at all times.
2.1. TOOL SPECIFICATIONS
XT1
Pull-Force: @5.5 bar 6.5 kN 1461 lbf
Air Supply Pressure: Min. to Max. 5.0 – 7.0 bar 72.5 – 101.5 lbf/in
2
Oil Pressure: Pull @ 5.5 bar 160 bar 2320 lbf/in
2
Stroke: Minimum Piston Stroke 17.8 mm 0.7 in.
Weight: Incl. nose equipment 1.17 kg 2.58 lb
Weight: without nose equipment 1.07 kg 2.36 lb
Free Air Volume: @ 5.5 bar 1.5 ltr 91.5 in
3
Cycle Time: Approximate 0.4 seconds
Noise Level:
Uncertainty noise: k= 3db(A)
77.95 dB(A)
Vibration Level: Uncertainty
vibration: k= 0.1 m/s
2
<2.5 m/s
2
<8.2 ft/s
2
