Stanley ProSet XT2 Service Manual

15
ENGLISH
5. SERVICING THE TOOL
5.1 MAINTENANCE FREQUENCY
Regular servicing must be carried out by trained personnel and acomprehensive inspection performed
annually or every 500,000 cycles, whichever is sooner.
DISCONNECT AIR SUPPLY
CAUTION - Never use solvents or other harsh chemicals for cleaning the non-metallic parts of the tool.
These chemicals may weaken the materials used in these parts.
5.2 NOSE EQUIPMENT
Nose assemblies need to be serviced at weekly intervals or every 5,000 cycles. Hold some stock of all internal
components of the nose assembly and nose pieces, they need regular replacement.
• Disconnect the air supply
• Remove the complete nose assembly using the procedure described in section 3.1.
• Inspect all components. Any worn or damaged parts must be replaced by anew part.
• Particularly check wear on the Jaws (1g).
• Clean all parts and apply moly lithium Grease (07992-00020) to jaws (1g) and taper bore of jaw guide (1f).
• Assemble according to tting instructions in section 3.2.
5.3 DAILY SERVICING
• Before use, check the tool, hose and couplings for air leaks and oil leaks. If damaged, remove the tool from
service and replace aected items with new parts.
• If there is no lter on the pressure regulator, bleed the airline to clear it of accumulated dirt or water
before connecting the air hose to the tool. If there is alter, drain it.
• Check that the nose equipment (1) is correct for the rivet to be placed and that it is tted properly.
• Check that the stroke of the tool meets the minimum specication (ref. 2.1).
• The mandrel collector (3) must tted to the tool.
• Check that the air chamber is fully tightened onto the tool body.
5.4 WEEKLY SERVICING
• Check the tool, hose and couplings for air leaks and oil leaks. If damaged, remove the tool from service
and replace aected items with new parts.
5.5 SERVICE KIT
For an easy complete service, Stanley Engineered Fastening oers the various tools below.
Item Part Number Description Item Part Number Description
1 PRL500-47 11 x 13 Double-end wrench 12 07992-00020 Grease - Moly Lithium
2 PSL600CJ-75 12 x 14 Double-end wrench 13 07992-00075 Grease - Molykote 55M
3 EN600-22 17 Single-ended wrench
4 07900-00158 2mm Pin Punch
5 07900-00164 Circlip Pliers
6 07900-00351 3mm Hexagonal Wrench
7 07900-00469 2.5mm Hexagonal Wrench
8 07900-00692 Trigger Valve Extractor
9 07900-00692 Trigger Valve Extractor
10 07900-00700 Priming Pump Assembly
11 07900-00755 Grease - Molykote 111
