ENGLISH

Item Drawing Number Description QTY

Spares

MOQ

Item Drawing Number Description QTY

Spares

MOQ

1a PRN414 NOSE PIECE 1 34 DPN901-022 SPRING 1

1b PRN314 NOSE PIECE 1 35 DPN276-014 MCS VALVE ROD 1

1c PRN514 NOSE PIECE 1 36 DPN900-066 O-RING 2

1d TP144-111 NOSE HOUSING 1 37 DPN900-065 O-RING 2

1e TP144-091 O-RING 1 38 TP144-175 MCS VALVE CASE 1

1f DPN239-006 JAW GUIDE 1 39 TP144-142 MCS VALVE PUSHER 1

1g PRG402-8A JAWS 1set 40 TP144-084 UPPER GASKET 1

1h TP144-117 JAW PUSHER 1 41 TRM00216 HANDLE ASSEMBLY 1

1i TP144-118 URETHANE WASHER 1 42 TRM00249 HANDLE SEALING SKIRT 1

1j TP144-119 JAW PUSHER SPRING 1 43 TP144-085 LOWER GASKET 2

1k TP144-120 MANDREL GUIDE 1 44 TP144-086 UPPER PLATE 1

1l TRM00167 PULLING HEAD 1 45 07005-00088 SCHRADER VALVE 1

1m TP144-113 JAW GUIDE LOCK 1 46 76003-02024 TRIGGER PIN 1

1n TP144-114 JAW GUIDE LOCK SPRING 1 47 07003-00042 O-RING 1

2 TP144-171 SUSPENSION HOOK 1 48 71210-03402 VALVE SPOOL MOULDED 1

3 TRM00227 COLLECTOR BOTTLE ASSEMBLY 1 49 07003-00268 O-RING 1

4 07001-00405 BLEED SCREW 1 50 DPN239-089 PLUG 1

5 07003-00194 BONDED SEAL 1 51 DPN900-045 O-RING 1

6 76003-02008 TRIGGER BUTTON 1 52 TP142-036 HANDLE LOWER 1

7 TRM00221 ON OFF VALVE ASSEMBLY 1 53 76001-02029 POP AVDEL LABEL 1

8 TP144-115 LOCK NUT 1 54 TP144-097 O-RING 1

9 TRM00215 HANDLE UPPER ASSEMBLY 1 55 TP144-078 VALVE SEAT SLEEVE 1

10 76001-02027 PROSET XT1 LABEL 2 56 07003-00281 O-RING 2

11 76001-02028 SAFETY LABEL 1 57 71210-02009 VALVE SEAT 1

12 TP144-159 SCRAPER 1 58 TP144-087 SLEEVE WASH 1

13 TP144-174 O-RING 1 59 TP144-054 SLEEVE LOCK NUT 1

14 TP144-062 ROD SEAL CASE 1 60 TRM00217 SEAL ASSEMBLY 1

15 76002-02021 BEARING TAPE 1 61 TRM00218 AIR PISTON ASSEMBLY 1

16 07003-00515 ROD SEAL 1 61a 71210-03205 GUIDE RING 1

17 07003-00514 PISTON SEAL 1 61b TP144-099 O-RING 1

18 TRM00161 HYDRAULIC PISTON 1 61c TP144-102 MINI Y PACKING 1

19 76002-02026 BEARING TAPE 1 61d TP144-104 R TYPE RETAINING RING 1

20 TP144-154 O-RING 1 61e TP144-083 EXT VALVE SPRING 1

21 07003-00516 O-RING 1 61f TP144-075 EXHAUST VALVE BODY 1

22 TP144-150 EJECTOR BODY 1 61g TP144-103 CR TYPE RETAINING RING 1

23 TP143-123 EJECTOR NOZZLE 1 62 TRM00219 TUBE VALVE ASSEMBLY 1

24 TP144-094 O-RING 2 63 TRM00220 TUBE ASSEMBLY 1

25 TP144-082 RETURN SPRING 1 64 TP144-077 VALVE PLATE 1

26 TP153-112 END CAP 1 65 TP144-108 HEXAGONAL SOCKET HEAD CAP BOLT 2

27 TP154-110 O-RING 1 66 TP144-098 O-RING 1

28 TP153-111 COLLECTOR ADAPTER MOULDING 1 67 TP143-125 CHAMBER 1

29 TRM00250 O-RING 1 68 TP142-110 CHAMBER PROTECTOR 1

30 DPN900-017 O-RING 1 69 TRM00238 NOSE HOUSING NUT 1

31 TP144-063 EJECTOR GUIDE 1 70 DPN900-004 O-RING 1

32 71213-05101 STEM DEFLECTOR 1 71 TP144-178 MANDREL GUIDE ASSEMBLY 1

33 TP144-064 DEFLECTOR RETAINING NUT 1
