2.4 MAIN COMPONENTS LIST
Refer to gure 1 & 2 and the table below.
Item Part Number Description Qty
1 TRM00360 Standard nose equipment XT1 tool 1
TRM00361 Standard nose equipment XT2 tool
2 TP144-171 Suspension hook 1
3 TRM00227 Mandrel collector 1
4 07001-00405 Oil plug 1
5 07003-00194 Seal 1
6 76003-02008 Trigger 1
7 TRM00221 On/O valve 1
2.5 STANDARD NOSE EQUIPMENT
Refer to gure 2 and the table below.
Item XT1 tool Part
Number
XT2 tool Part
Number
Description Qty
1a PRN314 - Nose Piece - 2.4mm [3/32“]1
- PRN614 Nose Piece - 4.8 mm [3/16“] ( tted on
XT2)
1b PRN414 PRN414 Nose Piece - 3.2 mm [1/8“] ( tted on XT1) 1
1c PRN514 PRN514 Nose Piece - 4.0 mm [5/32“]1
1d TP144-111 TP144-048 Nose housing 1
1e TP144-091 TP144-091 O-ring 1
1f DPN239-006 DPN275-001 Jaw guide 1
1g PRG402-8A 71210-15001 Jaws 1 Set
1h TP144-117 TP144-050 Jaw pusher 1
1i TP144-118 TP144-088 Urethane washer 1
1j TP144-119 TP144-081 Jaw pusher spring 1
1k TP144-120 TP144-052 Mandrel guide 1
1l TRM00167 TRM00165 Pulling head 1
1m TP144-113 TP144-051 Jaw guide lock 1
1n TP144-114 TP144-080 Jaw guide lock spring 1
1o DPN900-004 DPN900-002 O-ring 1
1p TRM00238 TRM00239 Nose Housing Nut 1
For additional nose equipment please refer to the ProSet
®
Nose Equipment Manual 07900-09412 or visit
www.stanleyengineeredfastening.com/resource-center/document-library
For a full list of tool accessories, please refer to the ProSet Accessories Manual 07900-09413.
