ENGLISH
8
2. SPECIFICATIONS
The ProSet
®
XT1 & XT2 are hydro-pneumatic tools designed to place Stanley Engineered Fastening blind rivets
at high speed The tools feature a vacuum system for rivet retention and trouble free collection of the spent
mandrels regardless of tool orientation.
When coupled to the relevant nose equipment the ProSet
®
XT1 & XT2 can be used to place blind rivets in the
range of Ø 2.4mm to Ø 4.8mm. Refer to the table on page 7 for a list of all rivets that can be placed.
The safety warnings on pages 4 & 5 must be followed at all times.
DO NOT use under wet conditions or in the presence of ammable liquids or gases.
2.1. TOOL SPECIFICATIONS
XT1 XT2
Pull-Force: @ 5.5 bar 6.5 kN 1461 lbf 8.9 kN 2001 lbf
Air Supply Pressure: Min. to Max.
5.0 - 7.0 bar 72.5 - 101.5 lbf/in
2
5.0 - 7.0 bar 72.5 - 101.5 lbf/in
2
Oil Pressure: Pull @ 5.5 bar 160 bar 2320 lbf/in
2
210 bar 3045 lbf/in
2
Stroke: Minimum Piston Stroke 17.8 mm 0.7 in. 19.8 mm 0.79 in.
Weight: Incl. nose equipment 1.23 kg 2.58 lb 1.32 kg 2.78 lb
Weight: without nose equipment 1.11 kg 2.36 lb 1.17 kg 2.54 lb
Free Air Volume: @ 5.5 bar 1.5 ltr 91.5 in
3
2.5 ltr 134.2 in
3
Cycle Time: Approximate 0.4 seconds 0.6 seconds
Noise values determined according to noise test code ISO 15744 and
ISO 3744.
XT1 XT2
A-weighted sound power level dB(A), L
WA
Uncertainty noise: k
WA
= 3.0 dB(A) 89.9 dB(A) 89.5 dB(A)
A-weighted emission sound pressure level at
the work station dB(A), L
pA
Uncertainty noise: k
pA
= 3.0 dB(A)
78.9 dB(A) 78.5 dB(A)
C-weighted peak emission sound pressure
level dB(C), L
pC
, peak
Uncertainty noise: k
pC
= 3.0 dB(C)
80.4 dB(C) 78.9 dB(A)
Vibration values determined according to vibration test code ISO
20643 and ISO 5349.
XT1 XT2
Vibration emission level, a
hd
:
0.84 m/s
2
0.74 m/s
2
Uncertainty vibration: k 0.42 m/s
2
0.37 m/s
2
Declared vibration emission values in accordance with EN 12096
