6. Nose Extension Kits
Nose Extension Kits are supplied separately for tting to abase tool. Attached between the tool and the nose
assembly the extension allows access into deep channels. Refer to Table 5 below to select the correct Nose
Extension Kit for the Nose Assembly being used.
Table 5 - NOSE EXTENSION KITS - Compatability
Part Number Description
Compatible Nose Assemblies
Part Number Description
Nose Extension
Assembly
XT3 (Standard)
Standard Nose Assembly - Proset XT3 & XT4 Tools
Avdel Universal Nose Assembly - Proset XT3 & XT4 Tools
Avseal II Nose Assembly - Proset XT3 & XT4 Tools
Avseal II Nose Assembly - Proset XT3 & XT4 Tools
1/4“ Hemlok Nose Assembly - Proset XT3 & XT4 Tools
Avinox XT & Avibulb XT Nose Assembly - Proset XT3 &
XT4 Tools
Avseal II Nose Assembly - Proset XT3 & XT4 Tools
Nose Extension
Assembly
XT3 (nGenesis
Equipment)
Universal Nose Assembly for Genesis G2 tool
Extended Nose Assembly for Genesis G2 tool
Nose Assembly - 1/4“ Hemlok
Nose Assembly - 1/4“ Avibulb XT & 1/4“ Avinox XT
Standard Extension
for Maxlok
3/16“ Maxlok Nose Equipment
1/4“ Maxlok Nose Equipment
PREPARING THE BASE TOOL TO ACCEPT NOSE EXTENSION ASSEMBLY 76003-20200
IMPORTANT - READ THE SAFETY WARNINGS LISTED IN THE PROSET XT3 AND PROSET XT4 INSTRUCTION
MANUAL CAREFULLY BEFORE PUTTING INTO SERVICE.
IMPORTANT - THE AIR SUPPLY MUST BE TURNED OFF OR DISCONNECTED BEFORE FITTING OR
REMOVING THE NOSE EXTENSION KITS.
Refer to g. 13.
FIGURE 2
6
D
C
B
A
E
F
G
H
E
A
B
C
D
F
5
4
3
2
1
7
8
9
10
11
12
1
2
3
4
5
6
7
8
G
