Stanley ProSet XT3 User Manual

19
ENGLISH
FITTING THE FIXED COLLECTOR BOTTLE KIT
IMPORTANT - READ THE SAFETY WARNINGS LISTED IN THE PROSET XT3 AND PROSET XT4 INSTRUCTION
MANUAL CAREFULLY BEFORE PUTTING INTO SERVICE.
IMPORTANT - THE AIR SUPPLY MUST BE TURNED OFF OR DISCONNECTED BEFORE FITTING OR
REMOVING THE FIXED COLLECTOR BOTTLE KIT.
Refer to g. 16 and 17 and the table 9 below. Refer also to the Proset XT3 and Proset XT4 Service Manuals
07900-09410 and 07900-09411.
Table 9 - PARTS LIST - FIXED COLLECTOR BOTTLE KIT
76003-20500
Item Part Number Description Qty
XT3 Fixed Bottle Assembly
Fixed Bottle Adapter Assembly
Fixed Bottle End Cap Assembly
Retaining Nut
Seal
ORing
Sealing Plug
ORing
D
E
F
C
1 2 3 4
A
3 2 1 5
C
D
4 6 7 8
A
B
D
E
F
C
1 2 3 4
A
3 2 1 5
C
D
4 6 7 8
A
B
29-01-16 R. KING
DO NOT SCALE
Size:
ZA
Revision:
Scale:
DRAWING
NUMBER
1:1
1 of 1
A3
76003-20500(S)-ZA
Sheet:
MATERIAL
LIMITS
UNLESS
STATED
HEAT TREATMENT
DATE DRAWN
SURFACE TREATMENT
DRAWING
DESCRIPTION
ISSUE
C.N.
Avdel UK Limited
Pacific House, 2 Swiftfields,
Watchmead Industrial Estate,
Welwyn Garden City,
Hertfordshire, AL7 1LY
Registered in England: No. 315076
This document is the property of Avdel UK Limited
and is issued on the express terms that it is to be
treated as private and confidential and is not to
be communicated to any other person.
All patents, manufacturing and design rights are
reserved by Avdel UK Limited.
LUBRICATION
DIMENSIONS IN mm UNLESS STATED
REMOVE ALL BURRS AND SHARP EDGES
INCH DIMENSIONS IN PARENTHESES
0.13mm DECIMAL
N8
1/2 DEGREE ANGULAR
DRILL
SURFACE
TEXTURE
EN 20286/BS 1916-H11
15/245
ZA
PART
DESCRIPTION
PART
NUMBER
WEIGHT
B
Fig. 17
1
XT3 Fixed Bottle
Assembly
2
Fixed Bottle Adapter
Assembly
3
Fixed Bottle
End Cap Assembly
6
ORing
5
Seal
7
Sealing Plug
8
ORing
4
Retaining Nut
Item numbers in bold refer to g. 17 and table 9.
• The air supply must be disconnected.
• Install the Spring (76003-02030) into the recess in the Fixed Bottle End Cap Assembly (3).
• Attach Fixed Bottle End Cap Assembly (3), together with the Seal (5), ORing (6) and Spring (76003-02030)
to the tool head assembly and tighten with aspanner.
• Insert the Sealing Plug (7), together with ORing (8) fully into the bore in the tool head assembly.
• Assemble the Fixed Bottle Adapter Assembly (2) over the Fixed Bottle End Cap Assembly (3) and on to the
tool.
