Stanley ProSet XT4 Service Manual

ENGLISH
2.4 MAIN COMPONENTS LIST
Refer to figure 1 & 2 and the table below.
Item
Part Number Description
Qty
1
76003-15000 Standard nose equipment
1
2 76003-02022 Suspension hook
1
3 76003-05200 Mandrel collector
1
4
07001-00405
Oil plug 1
5 07003-00194 Seal
1
6 76003-02008
Trigger 1
7
76003-03700 On/Off valve
1
8
71210-02103 Locknut
1
2.5 STANDARD NOSE EQUIPMENT
Refer to figure 2 and the table below.
Item
Part Number Description Qty
1 a PRN414
Nose Piece - 3.2mm [1/81
1
1 b PRN514
Nose Piece - 4.0 mm [5/321
1
1c PRN614
Nose Piece - 4.8 mm [3/16'1 (Fitted)
1
ld PRN811
Nose Piece - 6.4 mm [1/41
1
1 e
76003-15001 Nose casing
1
if
07003-00067
0 ring 1
lg DPN276-001
Jaw guide
1
lh PRG540-44
Jaws 1 Set
li
DPN276-006 Jaw pusher
1
1j
DPN900-060
0 ring 1
lk
DPN901-019
Jaw pusher spring 1
11
76003-15002
Pulling head 1
lm
76003-15004 Jaw guide lock
1
In
DPN901-020
Spring 1
10
76003-15003 Pulling head adapter
1
1 p
07003-00277
0 ring 1
For additional nose equipment please refer to the ProSet° Nose Equipment Manual 07900-09414 or visit
www.stanleyengineeredfastening.com/resource-center/document-library
For a full list of tool accessories, please refer to the ProSet Accessories Manual 07900-09415.
POP a Avdel°

12
2.4 MAIN COMPONENTS LIST
Refer to gure 1 & 2 and the table below.
Item Part Number Description Qty
1 76003-15000 Standard nose equipment 1
2 76003-02022 Suspension hook 1
3 76003-05200 Mandrel collector 1
4 07001-00405 Oil plug 1
5 07003-00194 Seal 1
6 76003-02008 Trigger 1
7 76003-03700 On/O valve 1
8 71210-02103 Locknut 1
2.5 STANDARD NOSE EQUIPMENT
Refer to gure 2 and the table below.
Item Part Number Description Qty
1a PRN414 Nose Piece - 3.2mm [1/8”] 1
1b PRN514 Nose Piece - 4.0 mm [5/32”] 1
1c PRN614 Nose Piece - 4.8 mm [3/16”] (Fitted) 1
1d PRN811 Nose Piece - 6.4 mm [1/4”] 1
1e 76003-15001 Nose casing 1
1f 07003-00067 O ring 1
1g DPN276-001 Jaw guide 1
1h PRG540-44 Jaws 1 Set
1i DPN276-006 Jaw pusher 1
1j DPN900-060 O ring 1
1k DPN901-019 Jaw pusher spring 1
1l 76003-15002 Pulling head 1
1m 76003-15004 Jaw guide lock 1
1n DPN901-020 Spring 1
1o 76003-15003 Pulling head adapter 1
1p 07003-00277 O ring 1
For additional nose equipment please refer to the ProSet® Nose Equipment Manual 07900-09414 or visit
www.stanleyengineeredfastening.com/resource-center/document-library
For a full list of tool accessories, please refer to the ProSet Accessories Manual 07900-09415.
ENGLISH
12
