Stanley ProSet XT4 Service Manual

ENGLISH
5.5 SERVICE KIT
For an easy complete service, Stanley Engineered Fastening offers the complete Service Kit below.
Service Kit 76003-99990
Item Part Number Description Item Part Number Description
1
07900-00008 7/16 x 1/2 A/F Spanner 12 07900-00685 Insertion Rod
2
07900-00012 9/16 x 5/8 A/F Spanner 13 07900-00692 Trigger Valve Extractor
3 07900-00015 5/8 x 11/16 A/F Spanner
14
07900-00698 Stop Nut
4 07900-00158
2mm Pin Punch
15 07900-00700
Priming Pump Assembly
5 07900-00164
Circlip Pliers
16 07900-00706 Location Spigot Assembly
6 07900-00224 4mm Hexagonal Wrench 17 07900-00755 Grease - Molykote 111
7 07900-00351 3mm Hexagonal Wrench 18 07900-01085 Guide Tube
8 07900-00469 2.5mm Hexagonal Wrench 19 07900-01086 Piston Sleeve
9 07900-00670 Piston Bullet 20 07992-00020
Grease - Moly Lithium
10 07900-00672 Spanner Assembly 21 07992-00075 Grease - Molykote 55M
11 07900-00677 Seal Extractor
5.6 PRIMING
Priming is necessary after the tool has been dismantled and prior to operating. It may also be necessary to
restore the full stroke after considerable use, if the stroke has been reduced and fasteners are not now being
fully placed by one operation of the trigger.
Oil Details
The recommended oil for priming is HyspinsVG32 available in 0.51 (part number 07992-00002) or one gallon
containers (part number 07992-00006).
Priming Kit
To enable you to follow the priming procedure below you will need to obtain a priming kit.
Priming Kit 07900-00688
Item Part Number Description
1
07900-00351
3mm Hexagonal Wrench
2 07900-00700
Priming Pump
3 07900-00224
4mm Hexagonal Wrench
Priming Procedure
IMPORTANT - DISCONNECT THE TOOL FROM THE AIR SUPPLY OR SWITCH OFF AT ON/OFF VALVE
ASSEMBLY 7. REMOVE NOSE ASSEMBLY OR SWIVEL HEAD COMPONENTS.
All operations must be carried out on a clean bench, with clean hands in a clean area.
Ensure that the oil is perfectly clean and free from air bubbles.
Care MUST be taken at all times, to ensure that no foreign matter enters the tool, or serious damage may
result.
POP a Avdel°

16
5.5 SERVICE KIT
For an easy complete service, Stanley Engineered Fastening oers the complete Service Kit below.
Service Kit 76003-99990
Item Part Number Description Item Part Number Description
1 07900-00008 7/16 x 1/2 A/F Spanner 12 07900-00685 Insertion Rod
2 07900-00012 9/16 x 5/8 A/F Spanner 13 07900-00692 Trigger Valve Extractor
3 07900-00015 5/8 x 11/16 A/F Spanner 14 07900-00698 Stop Nut
4 07900-00158 2mm Pin Punch 15 07900-00700 Priming Pump Assembly
5 07900-00164 Circlip Pliers 16 07900-00706 Location Spigot Assembly
6 07900-00224 4mm Hexagonal Wrench 17 07900-00755 Grease - Molykote 111
7 07900-00351 3mm Hexagonal Wrench 18 07900-01085 Guide Tube
8 07900-00469 2.5mm Hexagonal Wrench 19 07900-01086 Piston Sleeve
9 07900-00670 Piston Bullet 20 07992-00020 Grease - Moly Lithium
10 07900-00672 Spanner Assembly 21 07992-00075 Grease - Molykote 55M
11 07900-00677 Seal Extractor   
5.6 PRIMING
Priming is necessary after the tool has been dismantled and prior to operating. It may also be necessary to
restore the full stroke after considerable use, if the stroke has been reduced and fasteners are not now being
fully placed by one operation of the trigger.
Oil Details
The recommended oil for priming is Hyspin® VG32 available in 0.5l (part number 07992-00002) or one gallon
containers (part number 07992-00006).
Priming Kit
To enable you to follow the priming procedure below you will need to obtain a priming kit.
Priming Kit 07900-00688
Item Part Number Description
1 07900-00351 3mm Hexagonal Wrench
2 07900-00700 Priming Pump
3 07900-00224 4mm Hexagonal Wrench
Priming Procedure
IMPORTANT - DISCONNECT THE TOOL FROM THE AIR SUPPLY OR SWITCH OFF AT ON/OFF VALVE
ASSEMBLY 7. REMOVE NOSE ASSEMBLY OR SWIVEL HEAD COMPONENTS.
All operations must be carried out on a clean bench, with clean hands in a clean area.
Ensure that the oil is perfectly clean and free from air bubbles.
Care MUST be taken at all times, to ensure that no foreign matter enters the tool, or serious damage may
result.
ENGLISH
16
