Stanley ProSet XT4 Service Manual

Item
1
Part Number
76003-15000
Description
Standard Nose Equipment (Includes 4 Nose Pieces)
Qty
1
Spares
Y
item
26
Part Number
07003-00507
Description
0 Ring
Qty
1
Spares
Y
la PRN414 Nose Piece - 32 mm Rivets 1 Y 27 76003-05104 Collector Adapter Moulding 1 Y
lb PRN514 Nose Piece - 4.0 mm Rivets 1 Y 28 76003-05101 Stem Deflector 1 Y
lc PRN614 Nose Piece -4.8 mm Rivets (Fitted) 1 Y 29 76003-05102 Deflector Retaining Nut 1 Y
1d PRN811 Nose Piece - 6.4 mm Rivets 1 Y 30 76003-05304 Spring 1 Y
le 76003-15001 Nose Casing 1 Y 31 76003-05300 MCS Valve Assembly 1 Y
1f 07003-00067 0 Ring 1 Y 32 76003-02014 Gasket 1 Y
lg DPN276-001 Jaw Guide 1 Y 33 76003-02016 Handle Assembly 1 Y
lh PRG540-44 Jaws 1 Set Y 34 76003-02025 Gasket 1 Y
1i DPN276-006 Jaw Pusher 1 Y 35 07005-00088 Trigger Valve 1 Y
lj DPN900-060 0 Ring 1 Y 36 76003-02024 Trigger Pin 1 Y
1k DPN901-019 Jaw Pusher Spring 1 Y 37 07003-00042 0 Ring 1 Y
ll 76003-15002 Pulling Head 1 Y 38 71210-03402 Valve Spool 1
lm 76003-15004 Jaw Guide Lock 1 Y 39 07003-00271 0 Ring 1 Y
1n DPN901-020 Spring 1 Y 40 71210-03401 Valve Body 1
10 76003-15003 Pulling Head Adapter 1 Y 41 07003-00268 0 Ring 1 Y
1p 07003-00277 0 Ring 1 Y 42 07003-00287 0 Ring 1 Y
2 76003-02022 Suspension Hook 1 Y 43 07005-01274 1/8' BSP Plug 1 Y
3 76003-05200 Stem Collector 1 Y 44 07003-00127 0 Ring 1 Y
4 07001-00405 M5 Socket Cap Head Screw 1 Y 45 74202-02090 POP-AVDEL Label 1 Y
5 07003-00194 M5 Bonded Seal 1 Y 46 76003-02001 Handle Base 1
6 76003-02008 Trigger 1 Y 47 07003-00281 0 Ring 2 Y
7 76003-03700 In-line On / Off Valve 1 48 71210-02009 Valve Seat 1 Y
8 71210-02103 Locknut 1 Y 49 76003-02015 Top Plate 1
9 07900-09404
Proset XT3 & XT4 Instruction Manual (not s hown) 1 Y 50 71210-02014 Clamp Nut 1 Y
10 71210-02104 Seal Housing 1 Y 51 76004-03800 Intensifier Seal Assembly- XT4 1 Y
11 07003-00333 Lip Seal 1 Y 52 76004-03200 Pneumatic Piston Assembly- XT4 1
12 76004-03300 Head Assembly-X74 1 52a 71230-03205 Guide Ring 1 Y
13 76004-02027 ProsetXT4 Label 2 Y 52b 07003-00509 0 Ring 1 Y
14 73200-02022 Safety Label 1 Y 52c 07003-00274 Rod Seal 1 Y
15 76003-02028 Bearing Ring 1 Y 52d 76003-03206 Spring 2 Y
16 07003-00273 Rod Seal 1 Y 52e 76003-03204 Exhaust Valve Body 1 Y
17 76003-02019 Seal Retainer 1 Y 52f TP144-103 Retaining Ring 2 Y
18 07003-00504 Piston Seal 1 Y 52g 76003-03205 Exhaust Valve Body- Short 1 Y
19 76004-02120 Piston Assembly-X74 1 53 76003-03500 Valve Rod Assembly 1
20 76003-02026 Bearing Tape 1 Y 54 76003-03600 Air Tube Assembly 1
21 07003-00505 Lip Seal 1 Y 55 07003-00510 0 Ring 1 Y
22 76003-02030 Spring 1 Y 56 76003-02002 Air Chamber 1
23 76004-05105 Ejector Nozzle - X74 1 Y 57 76003-02007 Air Chamber Sleeve 1 Y
24 07003-00511 0 Ring 2 Y 58 07003-00508 0 Ring 1 Y
25 76003-05110 End Cap Assembly 1 Y 59 07003-00530 0 Ring 1 Y
ENGLISH
6
5
Item Part Nu mber Description Qty Spares Item Part Nu mber Description Qty Spares
1 76003-15000 Standard Nose Equipment (includes 4 Nose Pieces) 1 Y 26 07003-00507 O Ring 1 Y
1a PRN414 Nose Piec e - 3.2 mm Rivet s 1 Y 27 76003-05104 Collector Adapter Moulding 1 Y
1b PRN514 Nose Piec e - 4.0 mm Rivet s 1 Y 28 76003-05101 Stem Deflec tor 1 Y
1c PRN614 Nose Piece - 4.8 mm Rivet s (F itted) 1 Y 29 76003-05102 Deflector Ret aining Nut 1 Y
1d PRN811 Nose Piec e - 6.4 mm Rivet s 1 Y 30 76003-05304 Spring 1 Y
1e 76003-15001 Nose Casing 1 Y 31 76003-05300 M CS Valv e Assembly 1 Y
1f 07003-00067 O Ring 1 Y 32 76003-02014 Gasket 1 Y
1g DPN276-001 Jaw Guide 1 Y 33 76003-02016 Handle A ssembly 1 Y
1h PRG540-44 Jaws 1 Set Y 34 76003-02025 G asket 1 Y
1i DPN276-006 Jaw Pusher 1 Y 35 07005-00088 Trigger Valv e 1 Y
1j DPN900-060 O Ring 1 Y 36 76003-02024 Trigger Pin 1 Y
1k DPN901-019 Jaw Pusher Spring 1 Y 37 07003-00042 O Ring 1 Y
1l 76003-15002 Pulling Head 1 Y 38 71210-03402 V alve Spool 1
1m 76003-15004 Jaw G uide Loc k 1 Y 39 07003-00271 O Ring 1 Y
1n DPN901-020 Spring 1 Y 40 71210-03401 V alve Body 1
1o 76003-15003 Pulling Head Adapter 1 Y 41 07003-00268 O Ring 1 Y
1p 07003-00277 O Ring 1 Y 42 07003-00287 O Ring 1 Y
2 76003-02022 Suspension Hook 1 Y 43 07005-01274 1/8" BSP Plug 1 Y
3 76003-05200 Stem Collect or 1 Y 44 07003-00127 O Ring 1 Y
4 07001-00405 M 5 S oc k et Cap Head Scr ew 1 Y 45 74202-02090 POP-AVDEL Label 1 Y
5 07003-00194 M 5 B onded S eal 1 Y 46 76003-02001 Handle Base 1
6 76003-02008 Trigger 1 Y 47 07003-00281 O Ring 2 Y
7 76003-03700 In-line On / Off Valv e 1 48 71210-02009 Valve Seat 1 Y
8 71210-02103 Locknut 1 Y 49 76003-02015 Top Plate 1
9
07900-09404
Pr oset XT3 & XT4 Inst r uc tion Manual (not shown) 1 Y 50 71210-02014 Clamp Nut 1 Y
10 71210-02104 Seal Housing 1 Y 51 76004-03800 Int ensifier S eal Assembly - XT4 1 Y
11 07003-00333 Lip Seal 1 Y 52 76004-03200 Pneumatic Piston A ssembly - XT4 1
12 76004-03300 Head Assembly - XT 4 1 52a 71230-03205 Guide Ring 1 Y
13 76004-02027 Pr oset XT4 Label 2 Y 52b 07003-00509 O Ring 1 Y
14 73200-02022 Safety Label 1 Y 52c 07003-00274 Rod Seal 1 Y
15 76003-02028 Bear ing Ring 1 Y 52d 76003-03206 Spring 2 Y
16 07003-00273 Rod Seal 1 Y 52e 76003-03204 Exhaust Valve B ody 1 Y
17 76003-02019 Seal Retainer 1 Y 52f TP144-103 Retaining Ring 2 Y
18 07003-00504 Piston S eal 1 Y 52g 76003-03205 Exhaust Valve Body - Short 1 Y
19 76004-02120 Piston Assembly - XT4 1 53 76003-03500 Valve Rod Assembly 1
20 76003-02026 Bear ing Tape 1 Y 54 76003-03 0 Air T ube Assembly 1
21 07003-00505 Lip Seal 1 Y 55 07003-00510 O Ring 1 Y
22 76003-02030 Spring 1 Y 56 76003-02002 Air Chamber 1
23 76004-05105 Ejector Noz zle - XT 4 1 Y 57 76003-02007 Air Chamber Sleeve 1 Y
24 07003-00511 O Ring 2 Y 58 07003-00508 O Ring 1 Y
25 76003-05110 End Cap Assembly
1 Y 59 07003-00530 O Ring 1 Y
60
