MICROLIFT OPERATION
8
SAFE OPERATION
OF CAR SHUTTER
To open the inner car shutter
safely, first lift the top section
until there is a gap of
approximately 300mm as
shown in Fig. 9.
To fully open the inner car
shutter, push down on the
bottom section until it is level
with the lift car floor as shown
in Fig. 10.
To close the inner car shutter,
gently lift the bottom section
until the two sections meet
together as shown in Fig. 11.
If this procedure is not
followed correctly there may
be a risk of injury if
the top shutter is opened
as shown in Fig. 12.
Fig. 9 Fig. 10
Fig. 11
Fig. 12
Please note that if the inner car shutter (which travel
with the lift car) or outer landing shutter (which is fixed
at each floor) is not correctly closed the red light will
not go out and the lift will not operate.
