StarTech.com ARMPIVOTB2 User Manual

5
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Table of Contents
Compliance Statements ........................................................................1
Warning Statements ..............................................................................2
Safety Statements ..................................................................................4
Product Diagram ....................................................................................6
Product Dimensions ..............................................................................7
Product Rotation ....................................................................................8
Product Information .............................................................................9
Specications..............................................................................................................................................9
Package Contents .....................................................................................................................................10
Installation ..............................................................................................12
Using the Grommet Mount ................................................................................................................... 12
Using the C-Clamp .................................................................................................................................... 14
Mounting the Monitor Arm ................................................................................................................... 17
Attaching a Monitor Using the VESA Mount ................................................................................... 19
Attaching an iMac Monitor .................................................................................................................... 20
Attaching the Monitor Mount .............................................................................................................. 24
Removing the Monitor Mount .............................................................26
Adjusting the Monitor Tilt ....................................................................26
Routing the Cables .................................................................................27

StarTech.com ARMPIVOTB2 Specifications

General

Certification	CE, TAA, REACH
Product color	Silver
Housing material	Aluminum
Sustainability certificates	RoHS
Mounting type	Desk
Maximum VESA mount	100 x 100 mm
Minimum VESA mount	75 x 75 mm
Maximum screen size	34 \
Minimum screen size	12 \
Desk thickness (max)	60 mm
Desk thickness (min)	20 mm
Maximum weight capacity	14 kg
Pan range	-180 - 180 °
Tilt angle range	-15 - 90 °
Angle of rotation	360 °
Wrench type	Hexagonal wrench
Wrench included	Yes
Number of screws	6
Master (outer) case width	480 mm
Master (outer) case height	31 mm
Master (outer) case length	700 mm
Harmonized System (HS) code	85299097
Quantity per master (outer) case	6 pc(s)

Weight and Dimensions

Width	320 mm
Height	520 mm
Weight	2500 g
Package depth	465 mm
Package width	225 mm
Package height	145 mm
Package weight	3200 g
