Instruction manual
9
Use the grommet mount to attach the ARMPIVOTV2
Warning! Make sure that the weight of the monitor doesn’t exceed the weight capacity
of this product. This product can support the following weight: Up to 8 kg (17.6 lb.).
Using the grommet mount to attach the ARMPIVOTV2 requires the assistance of a
second person.
1. Use a Phillips screwdriver to unscrew the screw and washer from the plate and
rod.
2. Remove the rod from the bottom of the desk clamp. (gure 4)
Tip! Keep the screw, washer, plate, and rod in a safe place so that you can use them
again if you want to switch back to the desk clamp.
gure 4
Desk clamp
Rod
Screw
Washer
Plate
