Instruction Manual
17
Control Command Format
If you would prefer to issue commands to the ST424HDBT using third party terminal
software please use the information below.
Note: Operation support for third party software is not supported by StarTech.com
Com Port Settings
Baud Rate: 9600 bps
Data bits: 8 bits
Parity: None
Stop bits: 1 bit
Flow control: None
Outport1 <“57” >“41”
1“09” 2“1D” 3“1F” 4“0D”
Outport2 < “1B” > “11”
1 “17” 2 “12” 3 “59” 4 “08”
Outport3 < “55” > “48”
1 “5E” 2 “06” 3 “05” 4 “03”
Outport4 < “07” > “40”
1 “18” 2 “44” 3 “0F” 4 “51”
Control Code
Command Format
cir + ‘_’ + code + ‘ ’
“cir” is the key word, ‘_’ is Space, “Code” is the Control code , ‘ ’ is carriage return.
