Instruction Manual
18
Example:
“ cir 40 ”(hex: 63 69 72 20 34 30 0D 0A), when the mx0404 received this command ,it
will change the Outport4 status to the next input port. ( “c”-0x63, ”I”-0x69, ”r”-0x72, ”
“-0x20, ”4”-0x34, ”0”-0x30, ‘ ’-0x0d0a)
Note: These commands can also be used in the Command box with the included
software. (Software Overview and Operation.)
Hexadecimal Code List
Command Code
Output1 previous: 0x63 0x69 0x72 0x20 0x35 0x37 0x0D 0x0A
Output1 next: 0x63 0x69 0x72 0x20 0x34 0x31 0x0D 0x0A
Output 1 select in1: 0x63 0x69 0x72 0x20 0x30 0x39 0x0D 0x0A
Output 1 select in2: 0x63 0x69 0x72 0x20 0x31 0x44 0x0D 0x0A
Output 1 select in3: 0x63 0x69 0x72 0x20 0x31 0x46 0x0D 0x0A
Output 1 select in4: 0x63 0x69 0x72 0x20 0x30 0x44 0x0D 0x0A
Output 2 previous: 0x63 0x69 0x72 0x20 0x31 0x42 0x0D 0x0A
Output 2 next: 0x63 0x69 0x72 0x20 0x31 0x31 0x0D 0x0A
Output 2 select in1: 0x63 0x69 0x72 0x20 0x31 0x37 0x0D 0x0A
Output 2 select in2: 0x63 0x69 0x72 0x20 0x31 0x32 0x0D 0x0A
Output 2 select in3: 0x63 0x69 0x72 0x20 0x35 0x39 0x0D 0x0A
Output 2 select in4: 0x63 0x69 0x72 0x20 0x30 0x38 0x0D 0x0A
Output3 previous: 0x63 0x69 0x72 0x20 0x35 0x35 0x0D 0x0A
Output3 next: 0x63 0x69 0x72 0x20 0x34 0x38 0x0D 0x0A
Output 3 select in1: 0x63 0x69 0x72 0x20 0x35 0x45 0x0D 0x0A
Output 3 select in2: 0x63 0x69 0x72 0x20 0x30 0x36 0x0D 0x0A
Output 3 select in3: 0x63 0x69 0x72 0x20 0x30 0x35 0x0D 0x0A
Output 3 select in4: 0x63 0x69 0x72 0x20 0x30 0x33 0x0D 0x0A
Output4 previous: 0x63 0x69 0x72 0x20 0x30 0x37 0x0D 0x0A
