9
WARNING!
When installing drain hose, x it properly with a rope.
If drain hose is too long, do not force it into washing machine as it will cause abnormal
noises.
Connect the other end of the inlet pipe to the inlet valve at the backside of product and fasten the
pipe tightly clockwise.
Water Inlet Valve Water Supply Hose
Drain Hose
WARNING!
Do not kink or protract the drain hose.
Position drain hose properly, otherwise damage might result from water leakage.
There are two ways to place the end of drain hose:
NOTE: If the machine has drain hose support, please install it as follows:
Water Trough
Max.100cm
Min.60cm
Trough
Hose Retainer
Max.100cmMax.100cm
Min.60cmMin.60cm
Max.100cmMax.100cm
Min.60cmMin.60cm
1. Put it into the water trough.
2. Connect it to the branch drain
pipe of the trough.
To Next Page
