Steelcase Empath - Standard or Trendelenburg Foot Tray Installation; Attach Rear Brackets; Install Front Bracket

Page 2 of 6
939599290 Rev C
Non-Locking Caster Replacement
1. Pull lever to recline chair.
2. Detach velcro strip and move cover to
gain access.
3. Use a 15/16” deepwell socket to remove
the nut that is securing the caster.
4. Remove the caster.
5. Reverse procedure to install
replacement caster.
NON-LOCKING CASTER
1
3
4
5
2
®
HEALTH
