Steelcase Migration SE - 3 Product description; 3.1 Specifications; 3.2 Components

Product description
_______________________________________________________________
153310 5
3 Product description
Dimensions and weight specifications of your product
can be found on the delivery note.
3.1 Specifications
Migration SE Desk &
Bench
Dimensions and weight
See delivery note
Temperature range at the
setup location
+5°C to +35°C
Relative humidity
5% to 80% (non-condensing)
Input voltage range
220 to 240 V ˜
Frequency range
50 to 60 Hz
Maximum load capacity
75 kg
Maximum “ON” duration
2 min. ON/18 min. OFF
Input current
2.5 A
Maximum adjustment range:
single telescope (Lift 1)
Double telescope (Lift 2)
720 mm to 1200 mm
650 mm to 1250 mm
Noise emission
<60 dB (A)
Max. power consumption
during lifting
240 W
Power consumption in
standby mode
≤ 0.2 W
Up/Down control panel
Standard
Memory control panel
Optional
Type plates are located on the controller housing, on
the columns and under the desktop near the control
panel.
Type plate: symbols – explanation
Double insulation. Double insulated
cables minimise the risk of electrical
shock.
For indoor use. Indicates that
placing the product outdoors is not
allowed.
CE marking. Used to symbolise the
conformity of the product with the
applicable requirements that the
European Community places on the
manufacturer.
Recycling symbol. Used to indicate
conformity with the regulations for
Waste Electric and Electronic
Equipment (WEEE) and the Electrical
and Electronic Equipment Act
(ElektroG). Electrical and electronic
products must be disposed of
separately from household waste at
the end of their service lives.
The CE marking is located on the underside of the
desktop and can be viewed at any time.
3.2 Components
The Migration SE Desk & Bench essentially
consists of the following components (the variant
descriptions can be found in the respective
chapters):
■ Desktop with plastic parts for desktop mounting
■ Software-supported and hardware-supported
stopping device with a sensor for system
protection
■ Migration SE Desk: Columns with bolted
65x25x2 mm steel pipe runner, including
adjusting screw to compensate for floor
unevenness, cable duct (optional)
■ Migration SE Bench: Columns without runners,
including adjusting screw to compensate for floor
unevenness, cross-member (welded), central
cable duct (optional).
■ Top plastic cap, left/right
■ Top cantilever, left/right (optional)
■ Horizontal structural profile section
■ Fixed height vertical variant
■ Optional electrical height adjustment:
– Lift 1: Electric motor (720 to 1200), in
column, including software-supported
stopping device and sensor
– Lift 2: Electric motor (650 to 1250), in
column, including software-supported
stopping device and sensor
– Power lift for lifting height adjustment
– Standard: Up/Down control panel
– Optional: Memory control panel with display
for height indication; function for
programming four desktop heights
All available components can be found in the
separate technical description and the price list.
