TUBE REPLACEMENT continued
D
E
F
INSTALL NEW TUBE
1. To install new tube, insert one fitting into slot, pull tube around the center of the roller
assembly and insert second fitting into the other slot. Illustration D
2. Align tube housing cover with track and slide over tube until fully closed. Illustration E
3. Plug the pump in.
4. Run the pump at full speed for one minute to relax the tube.
5. To lock cover in place, press down on the cover while turning the vertical tab 180
degrees from right to left. Illustration F
6. Run pump at full speed for one minute to verify operation.
7. Reconnect the suction and discharge lines.
8. Prime pump.
