9
USA and Canada 800.683.2378, International 904.641.1666 Stennicator
FLOW RATE OUTPUT
NOTICE: The information within this chart is solely intended for use as a guide. The output data is an approximation based on
pumping water under a controlled testing environment. Many variables can affect the output of the pump. Stenner Pump
Company recommends that all metering pumps undergo field calibration by means of analytical testing to confirm their outputs.
FLOW RATE OUTPUT
Item N
umber Prefix
Pump T
ube
Roller Ounce Pressure Milliliters Pressure
A
ssembly
p
er Minute
M
ax. psi per Minute Max. bar
E20MH H Black 2.7 80 74.0 5.5
Approximate Maximum Outputs @ 50/60Hz
NOTE: Duckbill check valve included with pumps rated 80 psi (5.5 bar) maximum.
Setting
Run Time
*
in seconds
Simplex Duplex
PRIME 60 60
1 PPG 22 11
1 PPL 63
10 PPG 21
*
Times are approximate (in seconds).
Key
PPG pulse per gallon
**
PPL pulse per liter
**
10 PPG is often referred to as 0.1 US gallons per pulse
