24
www.stenner.comEcon FP
PAUSE
Blue
Brown
(or Orange)
SECONDS
OR FLOW SWITCH
AUXILIARY
Black
Red
White
Green
Disassembled View of
Duckbill Check Valve
maximum 80 psi
Flow direction
of solution
Duckbill
INSTALLATION DIAGRAM featuring a Water Meter
Suction Line
Solution Tank
Disassembled
View
of nut and
ferrule
Shut-Off Valve
Discharge
Line
Grounded Power Outlet:
(Grounded-Fault Circuit-
Interrupter GFCI)
Water Meter
Output Cable
Connection
Pump Input
Signal Cable
Water Meter
Dire
ction o
f wate
r flow
