11
USA and Canada 800.683.2378, International 904.641.1666 Econ FP
CONTROL PANEL GUIDE – BUTTONS
The control panel has a backlit LCD display; when operating it will display the operating
modes and the % setting. The pump is factory pre-set at the lowest settings. The keypad is
locked and in standby mode.
To unlock the keypad, simultaneously press and hold and for 5 seconds. The
keypad will automatically lock if there is no operation for 60 seconds.
Following are the buttons for programming the modes of operation.
To prime the pump or run the pump at full speed, first press & continue to hold ,
then press .
To place the pump in or out of standby, first press & continue to hold , then
press . The pump will not respond to incoming signals when in STBY mode.
To select a mode of operation, first press & continue to hold , then press or
to scroll through the selections. The display will show FLOW SWITCH, AUXILIARY (for
12-24VAC/VDC), or SECONDS.
After the operational mode is selected, select the percentage setting. First press & continue
to hold , then press or until the desired percentage is reached.
STBY
MODE PRIME
MODE
MODE
or
%
M
ODE
%
MODE
%
or
PRIME
STBY
MODE
MODE
MODE
%
MODE
%
