Functional description
Button „Aerosol“
Press the „Aerosol“ button to switch on
aerosol nebulization. The medication
nebulization duration can be set to
between 5 and 30 min in the „System
Settings/Function“ menu. The nebu-
lization ends automatically at the end
of the set time or when the button is
pressed again. The button is green
while nebulization is in progress.
Aerosol nebulization is only possible if
O
2
is connected to the ventilator.
Lock/Unlock Touchscreen
Pressing the control knob for three
seconds will lock the touchscreen.
Press the control knob again for three
seconds to unlock the touchscreen.
When you tap the locked touchscreen,
a lock icon appears in the „System
Settings“ field.
Control knob „IGR“
Use the control knob to select and
activate all indirect functions.
The control knob has the following
functions:
• Switching within the menus
• Selecting and executing menu
functions
• Selecting and confirming parameter
settings
