SSD10000S - SSD10000S/3PH
28
8. Before moving off in the towing vehicle check the operation of the lights.
Fuel Filter (Water trap - element)
036-0028 230V Socket 16A 044-0002
Reset Button 16A 036-0049 115V Socket 32A 044-0003
Reset Button 30A 036-0052 230V Socket 32A 044-0004
Dust Cover IP23 Reset Button 036-0056 036-0039
1A Reset Button 036-0043 043-0007
Dust Cover (1 -2A Reset) 036-0077
Basic Kubota engines service kits are available form Stephill Generators, below are the individual parts
complete with part numbers.
4. Raise the jockey wheel by turning the handle and ensure the wheel is inline with the draw bar and is off the
ground. Release the jockey wheel clamp and raise the jockey wheel up to the draw bar. Re-clamp the jockey
wheel into this position.
Control Panel - AC Components - SSD10000S
6. Connect the 13-Pin plug to the towing vehicle socket. In some circumstances the plug may require an
adaptor to convert the lighting board standard 13-Pin plug to a 7-Pin plug to fit the towing vehicle socket.
7. Double check that the towing hitch is securely fitted to the towing vehicle tow bar, the breakaway cable is
fitted and light socket is secure.
STEPHILL GENERATORS LTD STRESS THAT THE ULTIMATE RESPONSIBILTY FOR THE SAFE
USE, SERVICE AND CONDITION OF THE TRAILER IS WITH THE OWNER/USER.
Kubota Consumable Service Spares
5. Connect the breakaway cable to the attachment point on the tow bar. Secure either around the hitch tow
ball or through the guide provided on the tow bar assembly.
3. Lower the hitch with the jockey wheel on to the tow ball, lifting the hitch handle while lowering until the
handle clicks. The green indicator on the hitch will be visible if the hitch has successfully fitted into position.
