Stephill SSD10000S - Control Panel and Operation; Control Panel Component Identification

SSD10000S - SSD10000S/3PH
7
Fig.2
1
AC Voltage Switch
2
Emergency Stop
3
Fuel Gauge
4
Main MCB & 230V RCD
5
115V Socket Outlets (Yellow)
6
Socket Outlet Reset Button(s)
7
230v Socket Outlets (Blue)
8
Earth Stud
9
Fuel Pump Prime Button
10
DSE 3110 Reset Buttons
11
DSE 3110 Control Module
1
400V Socket Outlet (Red)
2
230V Socket Outlet (Blue)
3
Emergency Stop
4
Fuel Pump Prime Button
5
Main RCBO
6
Earth Stud
7
Fuel Gauge
8
DSE 3110 Reset Buttons
9
DSE 3110 Control Module
Fig.3
Control Panel Identification
SSD10000S/3PH
Item No.
Description
SSD10000S
Item No.
Description
5
3
4
2
6
11
8
7
1
9
10
5
1
2
6
7
9
4
8
3
