Section 5.0: EST Overview
PREPARE THE EST EXTENSION ASSEMBLY
Key QTY Part Number Description
A 1 - Telescoping Pole Assembly
B 1 70-2019-01 BigIR EST Extension - Lower
C 1 70-2020-01 BigIR EST Extension - Upper
D 3 10-1059-11 Polyolefin Heat Shrink 2.05” x 4”
E 3 10-1104-11 O-ring, 1-3/4” x 2”
F 1 60-6000-20 Hose Clamp, 1.16” to 2“ ID, SS
G 1 60-1006-22 Quick Disconnect, 1-1/2” to 1-1/4”
H 1 10-1105-11 Vertical Pole Rain Cap
I 2 72-0046-01 BigIR Guy Kit
A
B
C
D
E
F
G
H
I
