Tech Support: consumer.steppir.com/support | 425.453.1910 | support@steppir.com
5
Antenna
Longest element 34ft (10.5m)
Weight 15lbs (6.8kg)
Wind load 1.9 sq. ft./0.17 sq. m.
Wind rating 100mph w/two guys
Adjustable elements 1-2
Power rating 3.0 kW (1500W limit on 60/80m
bands)
Feed points 1
Frequency coverage 3.4-55 MHz with loading coil, 7.0-
54MHz without
Control cable 2 x 4 conductor with coil, 1x without
ANTENNA SPECIFICATIONS
