It is important that you do an inventory of the items that were shipped to you. Nothing is worse than dis-
covering a day before a planned installation that there are missing parts! We do our very best to ensure that
you receive everything needed for construction of your antenna, but better to be safe than sorry—inventory
your parts well in advance of your installation. The items in blue represent available options — you will need
to check these items off only if you purchased them.
What Comes in the Box
✓ QTY PART #
DESCRIPTION
1 70-3410-01
EHU, BigIR Assembly
1 10-1501-22
Cover for Black EHU, No drain hole
1 70-3000-01
33 Volt supply with cord
1 21-6040
Splitter, 6" 3-1/2mm, Stereo Male to Two RCA Female
1 N/A
Orange Flash Drive containing manuals
1 72-0044-04 or -05
Kit, BigIR Mark IV Hardware/Heat Shrink
1 72-0044-11 or -12
Kit, BigIR EHU Wind Reinforcing Kit/ Mark IV Hardware
2 72-0046-01
Kit, BigIR MK III/IV Guy
1 70-6010-01
Adapter, 25pin Dsub Field Splice
1 10-1013-02
Telescoping Pole, 18 foot 4 section
1 70-2019-01
BigIR EST extension with aluminum coupler - Lower
1 70-2020-01
BigIR EST extension with aluminum coupler and ring - Upper
1 70-2021-01
CPVC Liner for BigIR, 89"x3/4", with coupler
1 70-2022-01
CPVC Liner for BigIR, 89" x 3/4", w/o coupler
1 10-1109-22
Antenna Support, 1-1/2, Vertical, Fiberglass
1 09729
SDA 100 Controller w/ TX Interface and SDA All Relay Board
or
09760
OptimizIR Controller
21-601_-01
Transceiver Interface Cable
06021
80m Base loading Coil for the BigIR
21-5001-01
Control cable, 4 conductor
21-7008-01
Balun 1:1 SO239 Connector, External Vertical or Dipole
20-8052-41
Filter, suppressor unit, 8 position, 65v
21-6002-09
Kit, Ground Mounted Vertical Radials, 4 wire, 9', (20-6m)
21-6002-16
Kit, Ground Mounted Vertical Radials, 4 wire, 16', (40-6m)
21-6002-40
Kit, Ground Mounted Vertical Radials Kit, 4 wire, 40', (80-6m)
PARTS CHECKLIST
