Figure 1.05 provides an overview of a SteppIR EHU (the specific model shown is a 20m driven).
EHU OVERVIEW
EHU terminal header
Spool with copper tape
Element Support Tube (EST)
Balun (yagi driven EHU only)
SO-239 (driven EHU only)
Sprocket/Stepper motor
Platen
Control cable routing tray
Figure 1.05
