OptimizIR recommended tuning frequencies
Please refer to the create/modify section of the controller manual for more information on tuning
OptimizIR Manual:
https://consumer.steppir.com/wp-content/uploads/2018/05/SDA-2000-OptimizIR-Manual-Version-1_4-April-17
-2018.pdf
HOW TO TUNE YOUR VERTICAL (MANDATORY)
Segment # Frequency (KHz)
Recommended Tune
Frequency (KHz) Untuned SWR
SWR Minimum
Frequency Tuned SWR
24 51000 52500
23 49500 50500
22 41000 41000
21 34500 34500
20 29000 29350
19 27500 28500
18 24600 24940
17 20800 21225
16 17850 18120
15 15800 15800
14 13850 14175
13 11300 11300
12 10000 10125
11 8850 8850
10 7850 7850
9 6950 7150
8 5300 5350
7 5200 5250
6 4100 4150
5 4000 4050
4 3750 3875
3 3600 3675
2 3500 3550
1 3400 3450
