2112 116TH AVE NE SUITE 1-5, BELLEVUE WA, 98004 WWW.STEPPIR.COM TEL: (425)-453-1910 FAX: (425)-462-4415
5
AUTOTRACK MODE
The AUTOTRACK mode must be toggled if the optional transceiver interface was purchased.
This function must be enabled via the Setup Mode. The antenna will be under the control of
the radio ONLY when in this mode. When under the control of the radio the antenna will be
re-optimized every 50 KHz and will follow the radio to any frequency within the range of the
antenna.
Using the other modes of NORM, 180 and BI can all still be used while in the AUTOTRACK
mode. By pressing the AUTOTRACK button so that the light is not lit is a very quick way to
disable automatic antenna frequency following.
NOTE:
The FREQUENCY ADJUST buttons are active when in this mode and will cause the antenna
to start to change frequency until the controller sees another command from the radio which
could be up to 2 seconds. Therefore you want to avoid accidentally hitting the band buttons
while using the transceiver interface to control the antenna.
The transceiver interface will update the frequency if it is enabled with the radio or computer
on overriding the band buttons almost immediately. If using the RETRACT button to home the
antenna the controller will override the tranciever interface and will go through an automatic
shut down once the elements are completely home.
SETUP MODE
The SETUP menu can be toggled by pressing the button on the front of the controller so that
the amber LED light is lit. This will change the screen so that it shows.
Once this screen appears on the display the BAND button will act as your scrolling button up
and down to select what option to modify. The following options can be selected in the
SETUP menu.
RETRACT ELMENTS
CALIBRATE
CREATE, MODIFY
TRANCEIVER SETUP
FACTORY DEFAULT
TEST MOTORS
OPTIONS MENU
Mode Key to EXIT
Up Dn to SCROLL
