CONNECTING THE AP
Next fi gure is an example of an infrastructure network incorporating the
COM-817. An Infrastructure network contains an access point or a
wireless router. For a typical connection of the AP, please do the
following:
1. You will need broadband Internet access (a Cable or DSL-subscriber
line into your home or offi ce). Consult with your Cable or DSL provider
for proper installation of the Modem.
2. Connect the Cable or DSL Modem to a Router. Quickly install the
router.
3. Locate an optimum location for the AP. The best place is usually near
the center of the area in which your PC(s) will wirelessly connect. The
place must accord with the Installation Environment Requirements.
4. Adjust the direction of the antenna. Normally, upright is a good
direction.
5. Connect the Ethernet Broadband Router to the COM-817. Power on
the AP.
6. If you are connecting a desktop PC or laptop to your network, install
the Wireless Adapter on the PC.
