APPENDIX C: SPECIFICATIONS
Frequency band: 2.4~2.4835GHz
Modulation: BPSK, QPSK, CCK, OFDM (BPSK/
QPSK/16-QAM/ 64-QAM)
Range: up to 100m
RF power: 17dBm
Antenna: 3dBi
Standards: IEEE 802.3, 802.3u, 802.11b and 802.11g
Protocols: TCP/IP, DHCP
Ports: One 10/100M Auto-Negotiation LAN RJ45
port supporting Auto MDI/MDIX
Cabling Type: 10BASE-T: UTP category 3, 4, 5 cable
(maximum 100m)
EIA/TIA-568 100Ω STP
(maximum 100m)
100BASE-TX: UTP category 5, 5e cable
(maximum 100m)
EIA/TIA-568 100Ω STP
(maximum 100m)
Radio Data Rate: 54/48/36/24/18/12/9/6Mbps or
11/5.5/3/2/1Mbps
Power Supply: 9V~ 0.8A
Operating Temperature: 32°F~104°F
Operating Humidity: 10% - 95% RH, Non-condensing
Dimensions: 6.2×4.3×1.3in (without antenna)
