3-5
Operating Instructions Operator Manual 068032
3.3 Independent
Foot Section
Operation
3.3.1 Independent
Operation
To adjust the foot section separately from the back section, support the foot
section with one hand, pull out the release lever then turn it clockwise. Adjust
the foot section to desired position and release the lever.
3.3.2 Return To Chair
Mode
To return the foot section to chair mode, support the foot section with one hand,
turn the release lever counterclockwise and push the release lever in. Adjust the
foot section until it locks into position.
Figure 3-6
Figure 3-7
