SPECIFICATIONS
STERISIL SYSTEM
17- 5/8”
17- 3/16”
17- 3/16”
5- 1/2”
6- 7/8”
Sterisil® Ac+System Specifications
Minimum Pressure 65 PSI
Maximum Pressure 85 PSI
Minimum Temperature 45°F
Maximum Temperature 100°F
Faucets (2) Sink with space for the faucet
Plumbing Drain Standard sink or floor drain
Electrical Outlets (1) Outlet 110V AC, 3 amp, GFCI, within 3' from system
Mounting Space System: 20"L x 9"W x 20"H
Bladder Tank Space Tank 2G: 12"H x 9"Dia
Tank 4G: 15"H x 12"Dia
Tank 10G: 21"H x 13"Dia
Tank 14G: 23"H x 15.25"Dia
INITIAL SETUP AND BASELINE REQUIREMENTS
For the system to fit functionally in its mounting, it will require at least:
• 20” in length
• 9” in width
• 20” in height
These dimensions allow for 2” of space on all sides of the system.
®
STERISIL® AC+ SYSTEM
