PHASE 1: UNPACKING AND INVENTORY
Carefully unpack the contents of the boxes. The standard Sterisil® Ac+System configuration is shipped
in two boxes. One box will include the Ac+ along with the installation manual, warranty registration
card, system mount, and assorted bags containing other needed items for installation. The water
storage tank will be shipped separately.
VERIFY THERE WAS NO DAMAGE DURING SHIPMENT. IF DAMAGE IS EVIDENT, CONTACT THE
SHIPPING COMPANY IMMEDIATELY.
TOOLS
Tools required for installation:
• Phillips head screwdriver
• Standard open end/box end wrenches ranging from ½” to ¾”
• Small to medium size adjustable wrench
• Standard hex key set
• Box knife
• Hand drill
• Phillips driver bits
• Universal drill bits: sizes 1/8” to ½” standard
• Level
• Schrader valved pressure gauge
• Low volume air pump
INVENTORY ITEMS MAY VARY DEPENDING ON SYSTEM SELECTION AND SPECIFIC PARAMETERS.
BOX 1:
• Sterisil® Ac+ System
• System mount (slide or hinged)
• Bag: (Manual, packing list, faucet sticker, tank sticker and warranty card)
• 10 ft 3/8” tubing
• 40 ft 1/4” tubing
• Autoclave Faucet (white) w/ 1/4” to 7/16” faucet connectors
• Cartridges (Stage 1, 2, 3, 4 [x3])
• Permeate Pump
• Blank Cartridge, clip and mounting screws
• UV Light transformer
• Large bag: Drain Saddle Valve, thread tape, Permeate Pump clip, 1/4” pressure gauge, 3/8”
pressure gauge, Flow Restrictor, modular coupler, stem elbow x3, Autoclave Disc, cables and RJ-12
connectors.
• Small bag: #10x1” mounting screws x8, sheet rock plastic anchors x8, supply tee, 1/4” Tank Ball
Valve, 3/8” Tank Ball Valve, Inline Ball Valve and Single Check Valve.
BOX 2:
Reserve Water Storage Tank
