7 Technical product information
7.1 CE Declaration and standards
This product complies with the regulations of the Medical Devices Directive and therefore
bears the CE mark.
Standard Denition/description Weight test dummy
EU guideline 93/42 EEC Applicable as mentioned in Appendix 1 N/A
NEN-EN 12182 (1999)
The requirements from EN12182 as mentioned in NEN-EN 12184 (1999):
Technical aids for the handicapped – General requirements and test methods
October 1997
125 kg
NEN-EN 12184 (1999)
Class C
Electric wheelchairs, scooters and accompanying battery chargers –
Requirements and test methods 2009
125 kg
ISO 7176-8
Requirements and test methods for static, impact and fatigue strengths July
1998
125 kg
ISO 7176-9 Climate tests for electric wheelchairs and scooters N/A
ISO 7176-14
Requirements and test methods for control systems for electric wheelchairs
1997
N/A
ISO 7176-16 Requirements for resistance to ignition of upholstered parts May 1997 N/A
The product has been EMC-approved (for electromagnetic compatibility) in accordance with EN12184 (1999).
7.2 Technical specications
Manufacturer Sunrise Medical HCM
®
Model Fortress Calypso 3 wheels (3W)
Fortress Calypso 4 wheels (4W)
Maximum user weight 125 kg (19.7 stone)
Description 3W 4W
Total length mm (inches)
1207 (47.5) 1214 (47.8)
Total width mm (inches)
622 (24.5) 622 (24.5)
Minimum height* mm (inches)
710 (28) 710 (28)
Total weight excluding batteries: kg (pounds)
70 (154.3) 75 (165.3)
Total weight including batteries: kg (pounds)
100 (220.5) 105 (231.5)
Weight of heaviest component kg (pounds)
27 (59.5) 32 (70.5)
Static stability in the downward direction °
15 (27%) 15 (27%)
Static stability in the upward direction °
15 (27%) 15 (27%)
Lateral static stability °
15 (27%) 15 (27%)
Distance range (ISO 7176-4)** km (miles)
40 (24.9) 40 (24.9)
Dynamic stability (max. safe slope) °
9 (16%) 9 (16%)
Maximum speed forwards km/h (mph)
12 (7,5)
10 (6)
12 (7,5)
10 (6)
Back angle, Captain Seat °
0-103-126 0-103-126
Seat depth, Captain Seat mm (inches)
445 (17.5) 445 (17.5)
Seat width, Captain Seat mm (inches)
457 (18) 457 (18)
Back height (excl. headrest), Captain Seat mm (inches)
406 (16) 406 (16)
Seat height (to platform), Captain Seat mm (inches)
432-490 min 420 - max 550
(min 16.5 - max 21.2)
(17-19.3) 432-490
min 150 - max 340
(min 5.9 - max 13.4)
min 150 - max 340
(min 5.9 - max 13.4)
(17-19.3) mm (inches)
260 (10.3) 260 (10.3)
Armrest height, Captain Seat mm (inches)
229-273 457 - 610 (18 - 24)
(9-10.8) 229-273
1250 (49.2) 1750
(9-10.8) mm (inches)
1650 (65) 1940 (76.4)
Distance between armrests, Captain Seat mm (inches)
457-610 100 (3.9)
(18-24) 457-610
70 (2.8) 70 (2.8)
(18-24)
Back angle, Master Seat °
85-180 85-180
Seat depth, Master Seat mm (inches)
430 (16.9) 430 (16.9)
